SMARTIA M630 PHOS
MINIMAL SLIDING INSULATED SYSTEM
Generic
WINDOW TYPE: Sliding
THERMAL INSULATION: Yes
EXTERIOR SHAPE: Flat
SURFACE TREATMENTS: Wood sublimation , Anodizing colors, all powder coating
Technical Characteristics
SASH DEPTH: 63 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT: Concealed profiles
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE): 44 mm
GLAZING TYPE: Double – Triple
MAXIMUM GLAZING THICKNESS: up to 32 mm
SASH WEIGHT: up to 250 Kg
SEALING METHOD: Perimetrical with tri-fin brushes
MINIMUM THRESHOLD HEIGHT: 32 mm
TYPE OF THERMAL INSULATION: Polyamides, Thermoplastic
Performance
UW: 1,43 W/m2K
WATER TIGHTNESS: CLASS 7A
AIR PERMEABILITY: CLASS 4
WIND LOAD RESISTANCE: C5
Characteristics
TYPES OF TYPOLOGY: Horizontal sliding sashes, Meeting stile, Combinations with fixed ligths
-
Description
The sliding system SMARTIA M630 PHOS offers a minimal touch in contemporary residences combining minimal design with high thermal performance. Following the “less is more” philosophy, all aluminium profiles can be hidden into the wall providing a total sense of comfort with top functionality and enhanced safety.
Advantages
Enhanced natural light thanks to the system’s minimal design and the wide glazing surfaces.
High energy saving thanks to the exceptional thermal performance.
Exceptional sound insulation.
Ease of access ideal for children, the elders and people with special needs.
Wide variety of typologies.
Special hotels solutions.
Maximum ease of use and high functionality.
Exceptional quality with certified performance.
