SMARTIA MD67
ENTRANCE DOORS INSULATED SYSTEM
Generic
THERMAL INSULATION: Yes
EXTERIOR SHAPE: Flat
Technical Characteristics
FRAME DEPTH: 67 mm
GLAZING TYPE: Double – Triple
MAXIMUM GLAZING THICKNESS: 23 up to 49 mm
MINIMUM THRESHOLD HEIGHT: 16 mm
TYPE OF THERMAL INSULATION: Polyamides 20 & 24 mm width, Insulation foam & ALUMIL Energy Bar
Performance
WATER TIGHTNESS: CLASS E1 350
AIR PERMEABILITY: CLASS 4
WIND LOAD RESISTANCE: C4/B4
BURGLAR RESISTANCE: RC2
Characteristics
UF: from 1,97 up to 3,15 W/m2K
SASH WEIGHT: Up to 220 Kg
SASH DEPTH: 67 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT: 117 mm
-
Description
SMARTIA MD67 is ALUMIL’s new system for quality main entrance doors. Distinguished for its modern design and its high performance, the system provides the ability to create entrance doors with panels or glazing infills. The special double-sided coplanar design provides unique entrance doors with exceptional aesthetic value.
Benefits
Maximum energy saving thanks to the exceptional thermal.
Modern design.
High security level.
Ease of access ideal for people with disabilities and children.
Exceptional sound insulation.
Ease of use and high functionality.
Wide variety of typologies.
Exceptional quality with certified performances.
