SMARTIA M12500 PHOS
MINIMAL SLIDING NON-INSULATED SYSTEM
Generic
WINDOW TYPE: Sliding
THERMAL INSULATION: No
EXTERIOR SHAPE: Flat
Technical Characteristics
SASH DEPTH: 45 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT: Concealed sash
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE): 72 mm
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE): 32 mm
GLAZING TYPE: Single – Double
MAXIMUM GLAZING THICKNESS: up to 32 mm
MECHANISM: Sliding mechanism
SEALING METHOD: Continuous perimetrical tri fin in two levels brush
MINIMUM THRESHOLD HEIGHT: Optional with conceal sash
Performance
WATER TIGHTNESS: CLASS 6A
AIR PERMEABILITY: CLASS 4
WIND LOAD RESISTANCE: C2/B2
Characteristics
TYPES OF TYPOLOGY: Combinations with fixed lights, Combinations with fly-screen and shutter, Horizontal Sliding, Meeting Stile
SASH WEIGHT: up to 250 Kg
-
Description
Discover the innovative SMARTIA M12500 PHOS, ALUMIL’s minimal sliding system designed to maximise the infusion of natural light. Its unique design seamlessly aligns with the latest architectural trends, making it a stylish addition to any space.
Advantages
Excellent value for money, combining affordability and high performance.
User-friendly and functional, making your daily interactions effortless.
Enhanced natural lighting thanks to product design and expansive window frames.
High level of security that allows you to rest easy knowing your home is well-protected.
High level of sound insulation, creating a serene and tranquil living environment shielded from unwanted noise.
Modern design that adds a touch of refined elegance to your home.
High quality and certified performance, ensuring long-lasting durability and reliability.
Increased static loads and functionality to remain steadfast even during severe weather conditions.
